Vacuum sealer 600 mm

The WHS-B-S600E is a heavy-duty vacuum sealer designed for industrial and food packaging applications requiring precision and scalability. Featuring a 600 mm Double Hot Wire sealing bar, with working stage, robust stainless-steel construction, and vacuum generation via compressed air, it ensures airtight protection for moisture-sensitive products during storage or transit.

Specifications:
Weight: 33 kg
Sealing length: 600 mm
Sealing width: 5 mm or 10 mm
Vacuum: Ejector system (compressed air)
Max vacuum strength: Up to 80 kPa
Vacuum control: Adjustable by vacuum level (kPa) or time (seconds)
Gas flushing: Timer-controlled for precise gas replacement
Compressed Air: 5–7 kgf/cm² (required)
Power supply: 1-phase, 110/220 V, 50/60 Hz

KEY FEATURES AND BENEFITS
Precision and durability

• Advanced HMI panel ensures precise sealing.
• Stainless steel construction for lasting performance.
• Double Hot Wire sealing bar for consistent, high-strength seals.
• Open housing design enhances heat dissipation for cooler, longer-lasting operation.

Operator convenience

• Multiple cycle modes (M1–M5) and specific modes for sealing (S) or vacuum-sealing (V).
• LCD displays real-time vacuum levels.
• Foot pedal allows hands-free bag positioning.

Safety and maintenance

• Key lock prevents unauthorized adjustments.
• Nozzle retracts after 60 seconds of inactivity.
• Sealing bar lifts 2 seconds after sealing.
• Safety sensor detects obstructions and lifts the bar immediately.
• Circuit-protection fuses prevent electrical overloads.
• Real-time diagnostics for quick troubleshooting.


WHY CHOOSE THE WHS-B-S600E?
The WHS-B-S600E stands out for its exceptional reliability, user-friendliness, and precision. Its Double Hot Wire sealing bar and compressed-air-driven ejector system ensure secure vacuum sealing of moisture barrier bags, protecting your products from contamination. With advanced features and industrial-grade construction, it is a trusted choice for high-quality sealing results.
