Tokyo Keiso CO., LTD.

VF-2200-series Vortex flow sensor

VF-2200-series Vortex flow sensor
Tokyo Keiso CO., LTD.

VF-2200-series Vortex flow sensor

Flow range of 10 - 150 L/min
No maintenance cost
Simple and compact design
Low pressure loss
Linear output
Product description
Specifications

VF-2200 is a vortex flow sensor for large flow and measures various types of liquid flow. Suitable for medium-scale facilities and lines for such sizes as 25 mm (1") and flow ranges of 10 - 150 L/min. The sensor body is made of PPS (Polyphenylene sulfide) and is designed to eliminate deposits.

Features

  • Flow range of 10 - 150 L/min
  • TS fitting and Flange fitting are available
  • Simple and compact design
  • No maintenance cost
  • Low pressure loss
  • Linear output
  • CE marking
Measuring medium Pure water, Water
Nominal diameter 25A
Flow range 10 to 150 L/min.
Fluid temperature 0 to 90 °C
Fluid pressure 0 to 0.98 MPa
Process Connection RC Screw, TS Socket, JIS10K Flange
Accuracy ± 3 % F.S.
